If your Admiral washing machine shows the W16 error code, it means the appliance has detected a drive motor fault. The drive motor is what powers the drum’s rotation during washing and spinning. Without it, your washer cannot agitate clothes or complete cycles effectively. While some W16 issues can be resolved with basic checks, others require professional repair.
What does the W16 error mean?
The W16 code appears when the washer’s system detects that the drive motor is either malfunctioning or not receiving the necessary power. This can be due to damaged wiring, a failed motor, or issues with the control board that sends signals to the motor. In some cases, the problem is triggered by a simple overload, which puts extra strain on the motor.
Common causes and fixes
1. Loose or Damaged Wiring
-
Cause: Vibration during cycles can loosen wiring connections between the motor and control board.
-
Fix: Disconnect power, remove the back panel, and inspect wiring for burns, corrosion, or loose plugs. Secure or replace damaged wiring as needed.
2. Faulty Drive Motor
-
Cause: Over time, the motor can wear out or develop internal faults.
-
Fix: If the motor hums but doesn’t turn, or is completely silent, it may need replacement. This is typically a professional job.
3. Control Board Malfunction
-
Cause: If the board fails to send the correct voltage to the motor, the drum will not move.
-
Fix: Requires a technician to test and, if necessary, replace the PCB.
4. Overloading the Washer
-
Cause: Excessive laundry weight can cause the motor to overheat or stall.
-
Fix: Remove some items, restart the cycle, and keep future loads within the washer’s recommended capacity.
When to call a technician
-
The W16 error returns after checking wiring and reducing load size
-
The motor shows no movement or response
-
You suspect PCB (Printed Circuit Board) damage
-
You hear grinding, burning smells, or other unusual noises during operation
A certified technician can run electrical tests, confirm whether the motor or control board is faulty, and perform safe replacements.
Conclusion
The W16 drive motor error in an Admiral washing machine can sometimes be solved with simple wiring checks or load adjustments. However, in many cases, it signals a need for professional repair. Prompt action will keep your washer running efficiently and prevent further damage to internal components.
